رد: التايفون كما يراها مصنعوها
لنفصل أكثر بلغة الأرقام
اولا: الأبعاد
DIMENSIONS / MASS
Wingspan 10.95 m (35 ft 11 in)
Length overall 15.96 m (52 ft 4 in)
Height 5.28 m (17 ft 4 in)
Wing Area 50.0 m2 (538 ft2)
Basic Mass Empty 11,000 kg (24,250 lb)
Maximum Take-off > 23,500 kg (51,809 lb)
Maximum external load > 7,500 kg (16,535 lb)
خصائص التصميم
DESIGN CHARACTERISTICS
Single seat twin-engine, with a two-seat variant
Weapon Carriage 13 Hardpoints
G’ limits +9/-3 ‘g’
Engines - Two Eurojet EJ200 reheated turbofans
max dry thrust class 60 kN (13,500 lb)
max reheat thrust class 90 kN (20,000 lb)
Maximum Speed Mach 2.0
الأداء العام
مع تسليح جو جو كامل
GENERAL PERFORMANCE CHARACTERISTICS
with a full Air-to-Air Missile Fit
Ceiling > 55,000 ft
Brakes off to 35,000 ft / M1.5 < 2.5 minutes
Brakes off to lift off < 8 seconds
At low level, 200 Kts to Mach 1.0 in 30 seconds
Maximum Speed Mach 2.0
Operational Runway Length < 700 m (2,297 ft)
لنفصل أكثر بلغة الأرقام
اولا: الأبعاد
DIMENSIONS / MASS
Wingspan 10.95 m (35 ft 11 in)
Length overall 15.96 m (52 ft 4 in)
Height 5.28 m (17 ft 4 in)
Wing Area 50.0 m2 (538 ft2)
Basic Mass Empty 11,000 kg (24,250 lb)
Maximum Take-off > 23,500 kg (51,809 lb)
Maximum external load > 7,500 kg (16,535 lb)
خصائص التصميم
DESIGN CHARACTERISTICS
Single seat twin-engine, with a two-seat variant
Weapon Carriage 13 Hardpoints
G’ limits +9/-3 ‘g’
Engines - Two Eurojet EJ200 reheated turbofans
max dry thrust class 60 kN (13,500 lb)
max reheat thrust class 90 kN (20,000 lb)
Maximum Speed Mach 2.0
الأداء العام
مع تسليح جو جو كامل
GENERAL PERFORMANCE CHARACTERISTICS
with a full Air-to-Air Missile Fit
Ceiling > 55,000 ft
Brakes off to 35,000 ft / M1.5 < 2.5 minutes
Brakes off to lift off < 8 seconds
At low level, 200 Kts to Mach 1.0 in 30 seconds
Maximum Speed Mach 2.0
Operational Runway Length < 700 m (2,297 ft)
