RABTA (C4I/ Air Defence Automation System)
A complete C4I system, that can interface all types of sensors (radars, sonars, IR sensors etc), to form a self-healing self-forming intelligent network. System supports upward, downward and lateral flow of information to bring all tiers of command at the same level of situational awareness. The system can interface to weapons as well, to pass on firing and control orders automatically.
RADAR INTERFACE & DAQ SYSTEM
The system is designed to acquire radar targets information present in the form of video/plot/track. For extracting this information, system supports a multitude of protocols (e.g., synchronous, asynchronous), electrical standards (e.g., RS-485, RS-422, RS232). System is configurable to receive target data from any standardized/known format.
RADAR DATA EXTRACTOR
Radar Data Extractor (RADEX) extracts digital target information by processing primary radar video. The RADEX is designed to accommodate variable scan rates and signal bandwidths of both short and long-range radars and utilize both normal and MTI video signals. It detects targets by correlating target 2-D profile with pre-stored profile. It precisely locates a target by finding maximum strength of radar video in a configurable 2-D region depending on time on target. All processing functions are fully configurable to adapt to specific customer needs. The main characteristics of RADEX include:
* 14-bit sampling at 0.25 Mhz to 20Mhz (max).
* Processing Channels: I/Q / MTI / Normal Video Processing.
* Dynamic Clutter Mapping.
* Target Capacity: 1600 Targets per Scan.
IFF DECODER
IFF Decoder provides digital target extraction for all ICAO and AIMS compliant interrogators. IFF Decoder interfaces directly to control centers or other downstream processors. In addition to providing high quality digital secondary target reports, IFF Decoder also correlates primary radar information from Radar Data Extractor.Main features of the decoder are:
* Processing Modes: 1,2,3/A and 3/C.
* IFF Video Sampling: Digital sampling at 4Mhz – 10Mhz (Max).
* IFF Video Processing: Digital/Analog IFF video processing
* Target Capacity: Up to 1600 reports per scan..
* Garbling Detection and resolution of both super imposed and interleaved target returns.
* Performs in the densest FRUIT environments through defruiting techniques.
RADAR DISPLAY CONSOLE (RDC)
AERO's Radar Display Console is a fully functional field proven Radar Display with powerful control features for the controllers/operators of the radar. Its integration with variety of radars is field proven. It can display raw radar video as well as processed target information.The numerous display settings/control features allow the controller/operator efficient air-space-management through Radar Display Console.
It has the following technical characteristics:
TECHNICAL CHARACTERISTICS
RAW VIDEO:
* Display of multiple videos in separate colors
* User configurable intensity control for all types of videos
PLOTS:
* IFF and fused plots have further classifications according to the military and civil aviation standards.
TRACKS/TRACKER TARGET DATA:
* Different types of targets (output from Multiple Radar Tracker) are displayed on the screen in accordance with MIL-STD-2525B.
BEARING LINES:
* User configurable Plot Suppression Areas and Video Suppression Areas in multiple shapes.
SYMBOLS:
* User can insert/remove different type of symbols of military importance
INTERCEPTION PROFILE GENERATION:
* Controllers/operators can generate interception profiles for the actual interception that is being carried out for the fighter aircrafts or for mock interceptions for training purposes.
* The fighter & target parameter information such as speed/heading/angles of turn etc are also calculated internally by the system upon each track update and are shown to the user.
VOICE SWITCHING SYSTEM (VSS)
Voice Switching System is designed to provide highly reliable, state-of-the-art, air-to-ground,ground-to-ground, and intercom communications for controllers of Military and civil air traffic; Air-to-ground communication interfaces provide connectivity between UHF, VHF and HF radio transmitters and receivers; Ground-to-ground communication interfaces provide connectivity to the public switched telephone network (PSTN), the defense switched network, long haul leased telephone lines, and the base telecommunications infrastructure; human interface to the communications network for safe and efficient communication control; each operator has the control to switch between any of the available radio and telephone channels; The Graphical User Interface (GUI) provides a flexible user configurable and friendly control.
MULTIPLE RADAR TRACKER (MRT)
* Can handle up to 2000 system tracks simultaneously.
* Can track maneuvers of up to 7 sustained Gs.
* Kalman filter based prediction engine.
* Dual mode association using both Nearest Neighbor (NN) and Joint Probabilistic Data Association (JPDA) algorithms.
* Provides option to force fuse tracks manually.
* Facilitates to exchange labels and change ids of tracks as desired.
AIR SITUATION DISPLAY (ASD)
* Compliant with mil-std-810E for anti-shock, anti-dust and weatherproof design.
* Compliant with mil-std-461 for electromagnetic interference.
* Mil-std-2525 compliant C4 I display with complete GIS support.
* Software can handle upto 2000 Tracks,2000 Symbols and 65535 vector areas simultaneously.
* Up to 255 vector maps can be overlayed simultaneously.
* Automatic interception profile generation feature to facilitate GCI operation.
THREAT EVALUATION AND WEAPONS ASSIGNMENT
Threat Evaluation and Weapons Assignment (TEWA) is an intelligent system designed to evaluate threats and engage weapons to these threats. TEWA detects hostile tracks and assigns a threat level to them. It determines all vital points and areas and calculate their threat scores and sorts out all those weapons that can engage these threats and assigns weapons to these threats.
FEATURES:
* Provides automatic air situation assessment.
* Warns system for incoming hostile tracks.
* Performs automatic threat evaluation and calculates threat level of these hostile tracks.
* Determines suitable weapons that can be used to engage these hostile tracks and engage appropriate weapons to these hostile tracks
* Guides fighters for interception.
WAR GAMING SYSTEM:
* An Air Defence war gaming system based on real-time adversarial head-to-head paradigm.
* Scalable architecture allows easy addition of new models.
* Recording and scenario saving options to facilitate review of player performance.
* Up to 255 players per team.
* Up to 255 referees to monitor the progress of the game.
* Integrated Threat Evaluation & Weapons Assignment module to facilitate tactics evaluation.
RADAR AUDIO VIDEO RECORDING SYSTEM
Radar Audio Video Recording System (RAVRS) is a device for automatic recording, storage and replay of the video information coming from radar as well as the voice information coming from multiple sources. RAVRS is a state-of-the-art technology in the field of digital data logging. It is a powerful system, designed to meet the growing needs in mission critical systems, of reliable audio and video recording.
TECHNICAL CHARACTERISTICS:
* 24 hours a day recording of digital radar video and audio data.
* Fast search of recorded data.
* Simultaneous recording and playback facility.
* Data archiving on internal hard disk (HDD) and external media (DVD-RAM).
* Synchronous playback of the multiple audio and video channels.
BASE OPS ROOM / FIC SOFTWARE
FEATURES:
* Two-way communication of tactical and operational data.
* Tabular display on remote and central command center.
* Handling of thousands of records simultaneously.
* Communication mediums can be dialup, leased line and hot lines.
* Time synchronization with external source and record's time stamping.
* System can be installed at ground stations, ships and air-crafts.
* Encryption is used for secure data transfer.
* Auto acknowledgment mechanism implemented to assure the data communication.
* Can be interfaced with any existing database.
* Cost-effective solution.
