AASM
© Dassault Aviation – S. Randé
The AASM (fr. Armement Air-Sol Modulaire), also marketed as ‘Hammer’, is a modular French guidance kit that is fitted to different sizes of normal ‘dumb’ bombs, to give them greater accuracy. The AASM is highly modular, and can include either laser- or electro-optical tracking, as well as a GPS-receiver, and is available in powered or unpowered versions. With all the bells and whistles, the weapon is closer to a guided missile than a traditional ‘smart bomb’. The issue is obviously that with the increase in capability comes a higher price, but that is a cost the French have been happy to pay for the ability to employ the weapon against high-priority targets. The AASM proved its worth when it allowed Rafales to fly the SEAD/DEAD mission over Libya and hunt down and destroy air defence assets. After full integration, which is set to become operational within the next few years, the ability to use the AASM for long-range high-off boresight attacks will become available to the Rafale.
Paveway
© Dassault Aviation – S. Randé
A number of laser-guided Paveways are integrated onto the Rafale, including the 227 kg GBU-12 Paveway II, GBU-22 Paveway III, and GBU-49 Enhanced Paveway, as well as the 454 kg GBU-16 Paveway II and the 908 kg Paveway III. Some of these very integrated at a very short notice, due to combat needs in Afghanistan and Mali.
Exocet
© Dassault Aviation – V. Almansa
A weapon currently only used by Aéronavale is the latest version of the legendary AM 39 Exocet. The latest Block 2 Mod 2 is a far cry from the weapons that wreaked havoc on the Royal Navy in the Falklands War, and the ability to employ Link 16 for targeting data allows the aircraft to acquire the target ‘silently’. Currently a single missile is carried on the centre-line, but the ability to carry up to three missiles is there.
SCALP
© Dassault Aviation – K. Tokunaga
The joint French-British SCALP, called Storm Shadow in the UK, is a stealthy long-range cruise missile. The missile is in many aspects similar to the JASSM currently employed by the Finnish Air Force, and it is not unlikely that the SCALP would replace the JASSM in the case either the Rafale or the Eurofighter would be chosen as our next fighter. A high-resolution IIR-seeker provides terminal guidance, and a number of different modes of operation can be set, including fusing (air burst, impact, or penetration) and dive angle. The weapon has also been successfully used in both Libya and Iraq. Navigation is via inertial, GPS, or terrain reference. The missile is designed to feature a very high level of automation on the part of the pilot, meaning that it is suitable for single-seat fighters as well as twin-seaters. It does currently lack a data-link, though future versions might include this feature.
Mica IR
© Dassault Aviation – K. Tokunaga
The Mica IR is the current standard heat-seeking missile of the Rafale, and as mentioned in the earlier post it is moonlighting as an IR-sensor fused with the rest of the fighter’s sensor suite. As an IR-missile, the MICA is something of an in-between, not being quite as manoeuvrable as ‘proper’ high-off boresight missiles such as the IRIS-T, and not featuring quite the range that the ASRAAM has. Still, it is able to perform lock-on after launch, and over-the-shoulder firings at targets behind the firing aircraft has been demonstrated, with the targeting data being provided by datalink.
Mica RF
© Dassault Aviation – S. Fort
The single major weak spot in the arsenal of the Rafale is the current beyond visual range missile, which is simply a Mica with an active radar seeker. The missile lacks the range and punching power of the AIM-120 AMRAAM, and as a matter of fact the above mentioned ASRAAM also has a higher kinetic energy at longer ranges. The sole benefit it has over the AMRAAM is that the US missile is something of a victim of its own success, with any potential adversary having spent serious resources studying how to defeat the AMRAAM, something which isn’t necessarily true for the Mica.
