“PL-13”
Another surprise in the imagery made available on Chinese web pages on January 4 was a curious computer-generated depiction of a missile called the “PL-13.” However, it must be stressed that this is the first image of this missile and a definitive determination of its existence and performance must await further disclosures. Arguing in favor of this program’s existence is the fact that its image appears with clear images of the PL-12 and the new PL-10, which would tend to lend credibility to the new missile depiction. In addition, Luoyang was reported to have been interested in ramjet propulsion to develop the PL-12.[13] This PL-13 image also points to the possibility that Vympel has sold China the technology needed to make such an AAM. The PL-13 image appears to show a two-intake ramjet motor, a configuration that Vympel had come to prefer as it was developing its R-77M-PD, following early 1990s collaboration with France’s former MATRA Corporation.[14] The ramjet intake shape on the PL-13 appears to conform to one known Vympel configuration. Furthermore, the four cruciform fins at the front end of the PL-13 are also characteristic of other Vympel missiles like the R-27, and Vympel was also reportedly discarding the “grid” shape fins for conventional fins,[15] which also coincides with the PL-13 image. Inasmuch as Russia apparently decided not to purchase the R-77M-PD, it is possible that Vympel was allowed to sell this missile technology to China.[16] But it is also possible that South Africa was a source for some AAM ramjet engine technology, inasmuch as South Africa also had an unrealized program called the Long Range Air-to-Air Missile (LRAAM).
