Paths for a future F4 standard
DSI May 2010
In 2019 or 2020 should start deliveries for tranche 5 Rafale, to be ordered late 2015. Already, the various stakeholders of the program are working to trace the contours of the standard - F4 - of these weapons systems. The PEA for exploring paths for capacitive improvements have started last fall. The aim is to commission a review of all areas, to examine every major system or equipment and try to evaluate which technology advances are expected to be at the rendez vous and those which couldn't be. Or those for whom it will be be possible to justify and obtain budgetary credits and those for whom it will not be possible! This explains the contents of this future F4 standard is still no freezed. However, the operationals are almost already expressing the considerable importance to dispose of a viewfinder-HMD. In A2A, it would allow one rafale to launch its MICA on a hostile aircraft without having to roll up in a close dogfight, which requires to be rid of its load of bombs. So to be able to continue its A2G original mission.
Essential viewfinder-HMD.
Beyond, the airmen consider that the viewfinder-HMD would provide an added value in the field of air-ground support, allowing to design to the weapon system, with the cross of the HMD, a ground target which would be in lateral or rear area and not necessarily, as it is the case today, in the front line sector of the aircraft. Or to design, via the Link-16, the ground target to a team member taking over. Thales evoked the possibility of an efficient equipment for the Rafale coming from the current Tiger HMD . And it seems quite clear that such equipment is much anticipated by potential export customers of the Rafale.
الحديث عن خوذه محددة للهدف وبالفعل حددت تاليس هدفها في خوذة تايجر الحالية
In the A2G field , operationals intend to have a laser designation pods even more efficient than the Damocles just arrived today in the qualification phase. They want the capacity to determine from a 6000 m altitude if the individual located on the ground is armed or not.
مطلوب بود جديد بديل للداموكليس حسنا نرحب الجديد pdl ng >>> وداعا لداموكليس
As for weapons, they evoke missille with double capacity air-ground and air-air. And for the AASM bombs, they emphasize the development, for the 250 kg bomb, of laser guidance in addition to the current route by GPS and inertial hybridized IR sensor, but also on the achievement for the 250 kg body , of modular charges adapted to various types of employment and target, for example to focus on the effects of detonation and reduce collateral damage. The operationals do not want the AASM 125 kg proposed by Sagem. However an AASM 1000 kg with the ability to penetrate bunkers and reinforced buildings is favorably mentioned.
طلبيات لقذائف 250 باوند من عائلة المطرقة
الطلبية تحديدا لنسخه موجهة ليزر من القنبلة 250 باوند
حسنا صورة لقنبلة 250 باوند بثلاثة رؤوس منها الليزري
Le 17 juin 2010, Sagem et la DGA ont réalisé avec succès le premier tir d’un démonstrateur de l’armement air-sol modulaire (AASM) de 250 kg dans sa nouvelle version à guidage terminal laser. La version à guidage GPS/inertiel/laser de l’AASM permet d’engager des cibles mobiles manœuvrantes, terrestres ou marines.
رابط
بعد شهرين من تقريرك تحقق مايريدون
The air-ground sensors of the weapon system should also provide very high definition modes to improve the tracking of ground target (GMTI GMTT modes for the radar) with more complex interweaving of air-ground and air- air modes (monitoring of aerial threats in various areas while providing a ground tracking function).
هذه طلبات الإمارات
The RBE2 air-to-ground modes include: Doppler Beam Sharpening (DBS) mapping; SAR mapping; Fixed Target Track (FTT); Sea Surface Search and Track While Scan; Ground Moving Target Identification and Track (GMTI/T); target acquisition and air-to-ground ranging. Terrain following and avoidance modes can be combined to generate 3-D radar maps, thus enabling full automatic terrain following flights using the radar only.
رابط
In the A2A field, one will have to start thinking about the studies for a MICA successor and to improve a little more the capabilities for identification of non-cooperative target (NCTR).
الميتيور دخل الخدمة على الرافال فعلا
بالنسبة لل ntcr
The present radar air-to-air modes include long-range search; multi target track and engagement; air combat modes; Non-Cooperative Target Recognition (NCTR); and look down/shoot down functions. In air-to-air mode, the RBE2 gives a tracking range beyond 60 nautical miles against a 30-square-foot target, with detection ranges up to 75 nautical miles. The radar can track and prioritize up to 40 targets simultaneously and engage up to eight with Mica, and soon Meteor, air-to-air missiles.
رابط
In the matter of data links, including the Link-16, one will have to make greater use of satellite links. And the sea serpent of steering nozzle for the M88 is discussed again. It is also question of developing a stealth kit. Work will be launched to reduce the RCS by modifying the coating of the cans under the Rafale.
فوهات العادم وتحدثت تاليس عن فوهات دفع موجه
INCAS [Insert New Additional Capacity for SPECTRA] for SPECTRA 5T.
Already, the authorities and industrials are preparing evolutions for SPECTRA , to allow it to remain very effective when will start coming the tranche 5 Rafale. The PEA INCAS (Insert New Additional Capacity for SPECTRA), notified last September by the DGA to Thales Airborne Systems and MBDA, is indeed preparing SPECTRA 5T. The real challenge, according to Thales engineers, is to think, not only about the original equipment on board the new tranche 5 Rafale, but also about the retrofit in the framework of a prospective site to put this future new standard for the rest of the fleet including the first Rafale delivered.
للجيل الجديد من الرافال وتعديل البدن للقديم لاستيعاب التطوير للسبيكترا حسنا اي ان هناك تعديل في البدن للطائرات الجديدة
An ambition much more delicate than it seems at first glance, because it need to evolve SPECTRA within acceptable limits - volume, mass, energy, cable, Interactions - by the first
ولكن عملية التعديل تتطلب تعديل القدرات والحجم والقدرة للنظام سبيكترا
Rafale series, although their architecture has been conceived in the late 1980s. This requires, according to Thales officials, treasures of cunning and ingenuity.
يحتاج الأمر مكر وذكاء
We must keep reaching an extreme interchangeability. Because the great longevity planned for the Rafale actually complicates the task. One need to design systems, allowing them the opportunity to integrate with minimal impact new technologies able to cope with post-2020 or even 2030 threats, still not easily discernible. As now formulated, the fundamental objective of SPECTRA 5T is therefore to be able to detect, even further, more discreet and even furtive threats.
وبالتالي التطوير يجب ان يجابه عدائيات مابعد 2030 اي اننا اليوم نستطيع مواجهة ماهو قبل 2030
اسمع للشرح كيف تكون الحيلة والمكر
How? by integrating, at the air entrances more efficient EM broadband receptors. Unlike current SPECTRA, with receivers still mixing analog and digital, those of SPECTRA 5T will be entirely digital. Which, incidentally, will facilitate transport and data management. More, added to future new processing algorithms, this increased "digitization" of equipement should provide a significant improvement in terms of sensitivity and angular measurement, with the added advantage of greater receptor compactness .
This will allow, with equal volume, to much more! It is certainly delicate, given the sensitivity of the topic,to enter further into the details of improvements in matter of performance and functionality. But it must be very clear: according to Thales engineers, it is a revolution for technology and capability at the same level as it is for the RBE2 Radar evolving from a passive PESA antenna to the active AESA.
الثورة التقنية واستمع
The GaN revolution.
This "revolution" also relates to jamming equipment for the future SPECTRA 5T. These transmitters, integrated at the top of the drift and the forward fuselage, near the apices and before the canard, will benefit from the integration of a new technology the gallium nitride (GaN) to replace the arsenide gallium currently used. The use of this broadband semiconductor, still unique within the European Union, very hard and with a very high thermal capacity, is expected to reduce significantly the electrical consumer and heating for a given power. The solid state antennas will provide a much greater lens precision with a very narrow emission beam. Note that to avoid any risk of external pressure on eventual Rafale export sales, the GaN components, like the gallium arsenide modules already used for the new RBE2 active antenna ,will be produced in France by a factory of the Franco-German company ( EADS / Thales joint-venture) UMS. The Thales engineers are also working to modify the current distribution between reception and jamming functions in SPECTRA. With, for example, the idea to integrate, for SPECTRA 5T, a multisignal RF receiver within the jammers. Viewing similarities between jammers and receivers components, such an approach would be technologically feasible and, potentially, would provide interesting synergies. Nevertheless, the collocation of such equipment would introduce real technical difficulties - EM compatibility -, though perfectly manageable. This pass, to avoid to perturb the receiver with collocated jamming emission, by appealing different waveforms for each equipment, with a wider range of frequence than currently employed on Spectra and with the implementation of active filters. In contrast, the locations and volumes vested to such equipment would remain unchanged from today. No way to modify anything in the aerodynamics of the aircraft or to impact the structure of the cell. Similarly, these changes would occur at energy isoconsumption [same energy consumption]. Asked whether the integration of tracted active EM decoys - in use with F/A-18E/F, B-1 and Typhoon - could be an interesting track for SPECTRA 5T, Thales engineers , as also the operationals, replied by expressing doubts about the broad effectiveness of the formula. It is difficult to re-roll the lure in flight and it must be dropped before landing. Hooked from a certain distance behind the carrier, it could allow a foreign fire control to recognize it as a decoy and, paradoxically, to facilitate the detection of the real target. Certainly, the tracted active EM jammer provides good angular jamming. But the SPECTRA ability to use jamming in cooperative mode - mode still insufficiently cleared by the operationals - is expected to balance the absence of tracted decoys on the Rafale.
What is almost certain, however, is that SPECTRA 5T will implement dropped active EM lures . They should be able to simulate the RCS of a Rafale and to track, thanks to the deployment of a small wing, a trajectory similar to the simulation of an airplane. This had already been the subject of studies and demonstration trials during the 1990s. It seems that the expected performance of these "dropped" lures are higher than those tracted. Nevertheless, studies will be launched to assess the interest of the latter. The carriage of additional IR cartridges on some external payload points is also expected. Although the PEA INCAS has been notified in November 2009, the study of the SPECTRA 5T architecture system have already made good progress. Suitable demonstrators for various equipment should begin to work next year.
