رد: القوات الجوية الجزائرية
لا تكن ببغاء وافهم التجهيزات الفرنسية الغيت واستبدلت كليا بهندية وروسية الهود وشاشات العرض هندية وتجهيزات الحماية الذاتية والتحذير روسية
وحتى لانكون كما تعتقد نحن لا نحرف الحقائق سواء المرة او الحلوة وحتى لا نجعل من النسخة الجزائرية طائرة ورقية نقول انها فعلا تمتلك تجهيزات حماية ذاتية لكنها للاسف غير كافية بما كان يمكن ان تكون عليه
نظام Missile Approach Warning system الروسي على النسخة الجزئارية وهو نفسه المركب على الهندية
Company
Airplanes
Logistic support
Exhibitions
Contacts
News
Projects
Gallery
Airplanes
Military Aircraft
Su-22М3
Su-22М4
Su-24МК
Su-25К
Su-27SК
Su-27UBK
Su-30МК
Su-32
Su-33
Su-35
Civil aviation
Projects
Museum
Search
Main page : Airplanes : Military Aircraft : Su-30МК : Aircraft performance
Aircraft performance
Historical background |
Aircraft performance |
Armaments |
Gallery |
Aircraft performance Takeoff weight:
- normal (including rockets 2xR-27R1 + 2xR-73E, 5270 kg fuel), kg 24,900* - maximum, kg 34,500 - max, kg 38,800 Maximum landing weight, kg 23,600 Max landing weight, kg 30,000 Maximum internal fuel, kg 9,640 Normal internal fuel, kg 5,270 Maximum ordnance, kg 8,000 Service ceiling (without external ordnance and stores), km 17.3 Maximum flight speed at sea level (without external ordnance and stores), km/h 1,350 Max Mach (without external ordnance and stores) 2.00 (1.9**) G-limit (operational) 9 Maximum flight range (with rockets 2xR-27R1, 2xR-73E launched at half distance):
- at sea level, km 1,270 - at height, km 3,000 - with one refuelling (at 1.500 kg fuel remaining), km 5,200 - with two refuellings in flight, km 8,000 Maximum airborne time (pilot-dependent), hours 10 Takeoff run at normal takeoff weight, m 550 Landing run at normal landing weight (with braking parachute), m 750 Aeroplane dimensions:
- length, m 21.9 - wingspan, m 14.7 - height, m 6.4 Crew 2
In-flight refuelling system Maximum flow rate (at entry pressure of 3.5 kg/cm 2), l/min 1,100
Powerplant Number and type of engines 2 x AL-31F (2 x AL-31FP***) Thrust in afterburner, kgf 12,500 -2 %
Avionics 1. Fire control system
1.1. Air-to-air fire control system
1.1.1. Search and track radar
1.1.2. IRST and laser rangefinder
1.1.2.1. Optical search and track station
1.1.2.2. Helmet-mounted target designator
1.1.3. Wide-angle HUD
1.1.4. IFF system interrogator
1.2. Air-to-surface fire control system
1.2.1. Coloured multi-purpose LCD indicators
1.2.2. Onboard digital computer
1.2.3. GPS satellite-based navigation system
1.2.4. Weapons control system
2. Aeroplane remote control system
3. IFF system transponder
4. Antenna feed system
5. Flight navigation system
5.1. Digital computer
5.2. Attitude and heading reference system
5.3. Short-range radiotechnical navigation system
5.4. GPS system
5.5. Autopilot system
5.6. Altitude and speed data processing and display system
5.7. Air data system
6. Electronic countermeasure equipment
6.1. Radar warning receiver with an expansion block
6.2. Chaff and heat flare dispenser
6.3. Radio jamming transmitter (in pod)
7. Communications system
7.1. VHF and UHF band communications transceiver
7.2. VHF and UHF band communications transceiver
7.3. SW band radio communications transceiver
8. Onboard automatic control system
8.1. Integrated onboard control and crew warning system
8.2. Flight information recording equipment
8.3. Onboard emergency situation warning equipment
9. Video recording system
9.1. Onboard video recorder
9.2. Forward vision video camera
9.3. Video controller
10. Aircraft responder
11. Telecommand homing system
12. Pod-type IRST and laser rangefinder
Limits Aircraft limit:
- SLL, hours 3,000 - to first overhaul, hours 1,500 - service life, years 25 Engine and outboard accessory-gearbox life:
- to first overhaul, hours 500 - service life limit, hours 1,500 *May vary depending on the equipment configuration installed upon customer's request
**With canard surfaces installed
***With thrust vector control engine installed
