رد: صناعه العسكريه باكستانيه
قذائف ٢٠٣م م صناعة الباكستانى
203MM HOW HE M 106
Specifications
Weight of shell91 kgWeight of filling16.5 kg of TNTFuzeMTSQ M582 A1 or PDM557 Propelling chargeSingle base, single perforatedGreen bagM1 (1-5)White bagM2 (5-7)PrimerPercussion type M-82
PERFORMANCE Muzzle velocity 594.4 metres/sec. Pressure 2,658 kg/sq.cm. Range 16,800 metres Chamber pressures for
performance proof tests:
Strength
Charge stability
Detonation 3,040+ 80 kg/sq.cm.
3,040+ 80 kg/sq.cm.
2,658 kg/sq.cm. http://www.pof.gov.pk/products/203mmhowmem106.htm
This ammunition is produced in following three versions :
COMPLETE ROUND
HE 19.07 kg 788 mm. Smoke WP 19.77 kg 788 mm. Blank 3.75 kg 372 mm.
PROJECTILE Body material Forged steel Filling: HE TNT, 2.13 kg SMOKEWhite Phosphorus, 1.8 kg, Tetryl Pellets, 105 gm. Fuze ( HE & Smoke) PDM 557
CARTRIDGE CASE Body materialDrawn brass 70/30 Propellant:HE&SmokeSingle base, flashless & smokeless M1 BlankWM017 Triple base propellant 660 gm. PrimerP-1, MK3, percussion type (HE, Smoke & Blank)
PERFORMANCE VELOCITY/RANGE: ACCURACY PE Horizontal 34.5 metres PE Vertical 9.0 metres
http://www.pof.gov.pk/products/105mmhow.htm
This is a long range separate loading variable charge ammunition to be fired through Soviet M46 and Chinese type 59 and 59-1 guns.
Specifications
Weight of filled projectile 33.4 kg (as fired) Projectile Forged steel shell filled with 3.44 kg TNT Fuze LIU-5 or ISC PF-1A Cartridge case Drawn brass 70/30 Propelling charge This ammunition is fired using either a
full or a reduced charge. The full
variable charge has two charge zones,
while the reduced variable charge has
three zones. Charge weight:
Reduced charge
Full charge
6.7 kg
12.90 kg Primer DI-5
PERFORMANCE Muzzle velocity 930 metres/sec. Pressure 3,150 kg/sq.cm. Range 27,490 metres Chamber pressures for
performance proof tests: Strength
Charge stability
Detonation
3,560+50 kg/sq.cm.
3,560+50 kg/sq.cm.
3,150 kg/sq.cm. http://www.pof.gov.pk/products/130mmhe.htm
قذائف ٢٠٣م م صناعة الباكستانى
203MM HOW HE M 106
Specifications
Weight of shell91 kgWeight of filling16.5 kg of TNTFuzeMTSQ M582 A1 or PDM557 Propelling chargeSingle base, single perforatedGreen bagM1 (1-5)White bagM2 (5-7)PrimerPercussion type M-82
PERFORMANCE Muzzle velocity 594.4 metres/sec. Pressure 2,658 kg/sq.cm. Range 16,800 metres Chamber pressures for
performance proof tests:
Strength
Charge stability
Detonation 3,040+ 80 kg/sq.cm.
3,040+ 80 kg/sq.cm.
2,658 kg/sq.cm. http://www.pof.gov.pk/products/203mmhowmem106.htm
قذائف 155mm صناعة الباكستانى
155 MM HOW HE M 107
Specifications
Weight of projectile43.2 kg (as fired)Weight of filling6.62 kg TNTFuzePDM 557 or MTSQM 582A1Propelling charge: Single baseGreen bagM3A1White bagM4A2Charge 8M119A2PrimerPercussion type MK 2A4 or M-82
PERFORMANCE
Muzzle velocity564 metres/sec.Pressure2,560 kg/sq.cm.Range1,8000 metres.Chamber pressures for performance proof tests:
Strength
Charge stability
Detonation
2,870+50 kg/sq.cm.
2,870+50 kg/sq.cm.
2,560 kg/sq.cm.
http://www.pof.gov.pk/products/155mmhowmem107.htm
155 MM HOW HE M 107
Specifications
Weight of projectile43.2 kg (as fired)Weight of filling6.62 kg TNTFuzePDM 557 or MTSQM 582A1Propelling charge: Single baseGreen bagM3A1White bagM4A2Charge 8M119A2PrimerPercussion type MK 2A4 or M-82
PERFORMANCE
Muzzle velocity564 metres/sec.Pressure2,560 kg/sq.cm.Range1,8000 metres.Chamber pressures for performance proof tests:
Strength
Charge stability
Detonation
2,870+50 kg/sq.cm.
2,870+50 kg/sq.cm.
2,560 kg/sq.cm.
http://www.pof.gov.pk/products/155mmhowmem107.htm
قذائف 105mm صناعة الباكستانى
]105MM How
]105MM How
This ammunition is produced in following three versions :
- HE Fired with normal bursting charge
- SMOKE WP Produces white smoke with incendiary effects
- BLANK Fired for ceremonial purposes
M1, M2A1, M2A2, M101/101A1, M102 & M106, (USA), L10/A1,
L-119 & M-119A1 (UK), L-5 (ITALY), KH178 (SOUTH KOREA),
TYPE 75 (JAPAN), LG-1 & M101A1 modernised (France) and many others
worldwide.
L-119 & M-119A1 (UK), L-5 (ITALY), KH178 (SOUTH KOREA),
TYPE 75 (JAPAN), LG-1 & M101A1 modernised (France) and many others
worldwide.
COMPLETE ROUND
WEIGHT
LENGTH
HE 19.07 kg 788 mm. Smoke WP 19.77 kg 788 mm. Blank 3.75 kg 372 mm.
PROJECTILE Body material Forged steel Filling: HE TNT, 2.13 kg SMOKEWhite Phosphorus, 1.8 kg, Tetryl Pellets, 105 gm. Fuze ( HE & Smoke) PDM 557
CARTRIDGE CASE Body materialDrawn brass 70/30 Propellant:HE&SmokeSingle base, flashless & smokeless M1 BlankWM017 Triple base propellant 660 gm. PrimerP-1, MK3, percussion type (HE, Smoke & Blank)
PERFORMANCE VELOCITY/RANGE: ACCURACY PE Horizontal 34.5 metres PE Vertical 9.0 metres
http://www.pof.gov.pk/products/105mmhow.htm
قذائف 122mm صناعة الباكستانى
122 MM HOW HE
This is a semi fixed ammunition for 122mm Howtizer type Model1954.
Specifications:
Weight of Projectile21.76 kg (as fired) ProjectileForged steel shell filled with 3.5 kg of TNT Fuze Percussion type LIU-4 Cartridge caseDrawn brass 70/30 Propelling chargeThis consist of a 9 charge single base i.e. a primary charge & two layers of four lower and upper charge bags Total propelling charge weight2.10 kg Primer percussion typeNo. 304
PERFORMANCE Muzzle velocity at full charge 515 metres/sec. Maximum range 11,800 metres
CHAMBERS PRESSURES FOR PERFORMANCE PROOF TESTS:-: Strength 2,580 +/- 40 kg/sq.cm Charge stability 2,580+/-40 kg/sq.cm. Detonation 2,350 kg/sq.cm. http://www.pof.gov.pk/products/120mmhowme.htm
122 MM HOW HE
This is a semi fixed ammunition for 122mm Howtizer type Model1954.
Specifications:
Weight of Projectile21.76 kg (as fired) ProjectileForged steel shell filled with 3.5 kg of TNT Fuze Percussion type LIU-4 Cartridge caseDrawn brass 70/30 Propelling chargeThis consist of a 9 charge single base i.e. a primary charge & two layers of four lower and upper charge bags Total propelling charge weight2.10 kg Primer percussion typeNo. 304
PERFORMANCE Muzzle velocity at full charge 515 metres/sec. Maximum range 11,800 metres
CHAMBERS PRESSURES FOR PERFORMANCE PROOF TESTS:-: Strength 2,580 +/- 40 kg/sq.cm Charge stability 2,580+/-40 kg/sq.cm. Detonation 2,350 kg/sq.cm. http://www.pof.gov.pk/products/120mmhowme.htm
قذائف 130mm صناعة الباكستانى
130 MM HE
130 MM HE
This is a long range separate loading variable charge ammunition to be fired through Soviet M46 and Chinese type 59 and 59-1 guns.
Specifications
Weight of filled projectile 33.4 kg (as fired) Projectile Forged steel shell filled with 3.44 kg TNT Fuze LIU-5 or ISC PF-1A Cartridge case Drawn brass 70/30 Propelling charge This ammunition is fired using either a
full or a reduced charge. The full
variable charge has two charge zones,
while the reduced variable charge has
three zones. Charge weight:
Reduced charge
Full charge
6.7 kg
12.90 kg Primer DI-5
PERFORMANCE Muzzle velocity 930 metres/sec. Pressure 3,150 kg/sq.cm. Range 27,490 metres Chamber pressures for
performance proof tests: Strength
Charge stability
Detonation
3,560+50 kg/sq.cm.
3,560+50 kg/sq.cm.
3,150 kg/sq.cm. http://www.pof.gov.pk/products/130mmhe.htm
