رد: الصناعة العسكرية الباكستانية
VEHICLE LAUNCHED ASSAULT TRACKWAY
Description
Rapid launching of trackway on affected ground
Time consuming, cumbersome and laborious retrieval by manual means avoided
Entire operation is controlled from vehicle’s cabin
Assault Trackway Class - 30 is a field expedient meant for laying over soft areas i.e., boggy, marshy, sandy patches or lengths of track likely to become degraded buy sustained traffic. The equipment enables carrying and launching of 50 meters length of special aluminum alloy trackway duly wrapped on its spool. The trackway permits mobility to vehicles / equipment upto 30 tons of combat weight. The launching vehicle is used for transportation as well as mechanical assisted launching / retrieval of the trackway. The launcher can easily launch / retrieve one 50 meter length within 10 - 20 minutes employing a crew of only three persons.
Specification
VEHICLE LAUNCHED ASSAULT TRACKWAY
SPECIAL FEATURES
Permits mobility to vehicles / equipment up to 30 tons weight Rapid launching of trackway on affected ground
Time consuming, cumbersome and laborious retrieval by manual means avoided
Entire operation is controlled from vehicle’s cabin
Assault Trackway Class - 30 is a field expedient meant for laying over soft areas i.e., boggy, marshy, sandy patches or lengths of track likely to become degraded buy sustained traffic. The equipment enables carrying and launching of 50 meters length of special aluminum alloy trackway duly wrapped on its spool. The trackway permits mobility to vehicles / equipment upto 30 tons of combat weight. The launching vehicle is used for transportation as well as mechanical assisted launching / retrieval of the trackway. The launcher can easily launch / retrieve one 50 meter length within 10 - 20 minutes employing a crew of only three persons.
Specification
TECHNICAL SPECIFICATIONS
Length of Each Plank
3.352 m (11 feet)
Width of Each Plank
0.257 m (10 inch)
Length of Trackway
50.292 m (165 feet)
Width of Trackway
3.352 m (11 feet)
Weight of Each Plank
16 Kg approx.
Weight of one set of Trackway (220 planks)
3400 Kg
Laying System
Power - assisted : driving power from vehicle's PTO. Operation Controlled from vehicle cabin.
Carrying Vehicle
5 ton tuck
Time for Laying and Retrieval
10 - 20 min
Crew
3 Persons
Length of Each Plank
3.352 m (11 feet)
Width of Each Plank
0.257 m (10 inch)
Length of Trackway
50.292 m (165 feet)
Width of Trackway
3.352 m (11 feet)
Weight of Each Plank
16 Kg approx.
Weight of one set of Trackway (220 planks)
3400 Kg
Laying System
Power - assisted : driving power from vehicle's PTO. Operation Controlled from vehicle cabin.
Carrying Vehicle
5 ton tuck
Time for Laying and Retrieval
10 - 20 min
Crew
3 Persons
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
HEAVY MECHANIZED BRIDGE
Description
Quick launching of bridge
Bridge retrieval from both ends
Bridge can sustain wheeled and military vehicles up to 18 and 50 tons capacity respectively
Set can meet different requirements of single as well as multiple span applications
This is a scissor type foldable steel bridge mounted on a 7.5 ton capacity vehicle. Each bridge section is 10 meters in span and is launched hydraulically. A combination of five bridge sections makes one set of 50 meters span. A bridge layer is composed of a bridge span, trestle, launching girder, bridge layer chassis and accessories. It can be recovered from home side as well as the far bank.
Specification
HEAVY MECHANIZED BRIDGE
SPECIAL FEATURES
Rapid bridging operation across wet and dry gaps Quick launching of bridge
Bridge retrieval from both ends
Bridge can sustain wheeled and military vehicles up to 18 and 50 tons capacity respectively
Set can meet different requirements of single as well as multiple span applications
This is a scissor type foldable steel bridge mounted on a 7.5 ton capacity vehicle. Each bridge section is 10 meters in span and is launched hydraulically. A combination of five bridge sections makes one set of 50 meters span. A bridge layer is composed of a bridge span, trestle, launching girder, bridge layer chassis and accessories. It can be recovered from home side as well as the far bank.
Specification
TECHNICAL SPECIFICATIONS
Maximum Carrying Capacities
50 ton (Tracked Vehicle)
18 ton (axle load capacity) (Wheeled Vehicle)
Width of Roadway
3.8 m (12.467 feet)
Length of a Single Span
10.5 m (34.45 feet)
Total Length of Bridge (one set)
50 m (164.05 feet)
Height of Bridge
3.8 m (12.467 feet) (max.)
2.2 m (7.218 feet) (min.)
Launching Time Required
6 - 8 min (Single span)
45 - 60 min (Whole set)
Allowable Current Velocity (Max.)
2 m / s
Operators Required
6 (Single span)
13 (Whole set)
Cruising Range
800 Km
Total Weight of Bridge Layer
About 20 ton
50 ton (Tracked Vehicle)
18 ton (axle load capacity) (Wheeled Vehicle)
Width of Roadway
3.8 m (12.467 feet)
Length of a Single Span
10.5 m (34.45 feet)
Total Length of Bridge (one set)
50 m (164.05 feet)
Height of Bridge
3.8 m (12.467 feet) (max.)
2.2 m (7.218 feet) (min.)
Launching Time Required
6 - 8 min (Single span)
45 - 60 min (Whole set)
Allowable Current Velocity (Max.)
2 m / s
Operators Required
6 (Single span)
13 (Whole set)
Cruising Range
800 Km
Total Weight of Bridge Layer
About 20 ton
التعديل الأخير:
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
HIGH PRESSURE AIR COMPRESSOR PLANT
Description
Multiple applications / usages
Can be used in extreme weather conditions
Incorporates safety devices at each stage of operation
Trailer-mounted high pressure air compressor plants have been developed by MVRDE for multiple applications. Custom-tailored compressors can be provided for special purposes or specific usages.
Specification
Compressor Section
Medium
Air
Suction Pressure
Atmospheric
Admissible Temperature in Compressor Compartment
Min. +1 to Max. +40 Degrees C
Admissible Air Intel Temperature for Compressor Compartment
Max. 40 Degrees C
Maximum Discharge pressure
250 Bar or 3625 psi
Volume Flow
90 CFM
Maximum Working Pressure
242 bar (3625 psi)
Power Supply
12 V DC
Engine
Type
Diesel (water cooled)
Power
IHP 136, BHP 100 approx.
Number of Cylinders
6
Clutch
Centrifugal Automatic
Power Supply
24 V DC
Electric System
Voltage
12 / 24 V heavy duty batteries with standard electrical fittings
HIGH PRESSURE AIR COMPRESSOR PLANT
SPECIAL FEATURES
Mobile, ease in transportation / air-lifting Multiple applications / usages
Can be used in extreme weather conditions
Incorporates safety devices at each stage of operation
Trailer-mounted high pressure air compressor plants have been developed by MVRDE for multiple applications. Custom-tailored compressors can be provided for special purposes or specific usages.
Specification
TECHNICAL SPECIFICATIONS
Dimensions
Length
12.60 m (41.34 feet)
Width
3.65 m (11.97 feet)
Height
3.42 m (11.22 feet)
Weight
3 ton approx.
12.60 m (41.34 feet)
Width
3.65 m (11.97 feet)
Height
3.42 m (11.22 feet)
Weight
3 ton approx.
Basic Features
Four stage high pressure, piston operated compressor (engine driven), air cooled, semi automatic function mounted on four - wheeled trailer. Compressor Section
Medium
Air
Suction Pressure
Atmospheric
Admissible Temperature in Compressor Compartment
Min. +1 to Max. +40 Degrees C
Admissible Air Intel Temperature for Compressor Compartment
Max. 40 Degrees C
Maximum Discharge pressure
250 Bar or 3625 psi
Volume Flow
90 CFM
Maximum Working Pressure
242 bar (3625 psi)
Power Supply
12 V DC
Engine
Type
Diesel (water cooled)
Power
IHP 136, BHP 100 approx.
Number of Cylinders
6
Clutch
Centrifugal Automatic
Power Supply
24 V DC
Electric System
Voltage
12 / 24 V heavy duty batteries with standard electrical fittings
التعديل الأخير:
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
Establishment60 TON SEMI TRAILER
Description
Provide uniform payload support
Can perform both on metallic roads and shingle / dirt tracks
Low bed platform provides more overhead clearance
Goose-neck configuration facilitates better turning performance
It is a semi - trailer having employed as standard tank transporter. It utilizes four dual axles in "Rocker Beam" configuration with 16 tyres designed to support the payload uniformly under all terrain conditions. It is capable of carrying all military vehicles and tanks upto 60 tons combat weight.
Specification
Establishment60 TON SEMI TRAILER
SPECIAL FEATURES
Capable of carrying military equipment up to 60 tons weight Provide uniform payload support
Can perform both on metallic roads and shingle / dirt tracks
Low bed platform provides more overhead clearance
Goose-neck configuration facilitates better turning performance
It is a semi - trailer having employed as standard tank transporter. It utilizes four dual axles in "Rocker Beam" configuration with 16 tyres designed to support the payload uniformly under all terrain conditions. It is capable of carrying all military vehicles and tanks upto 60 tons combat weight.
Specification
TECHNICAL SPECIFICATIONS
Principal Dimensions and Weight
Length
12.60 m (41.34 feet)
Width
3.65 m (11.97 feet)
Height
3.42 m (11.22 feet)
Loading Platform Height (Laden)
1.30 m (4.26 feet)
Length of Platform (including slope)
8.70 m (28.54 feet)
Loading Area Length
7.60 m (24.93 feet)
Ground Clearance
0.35 m (1.15 feet)
12.60 m (41.34 feet)
Width
3.65 m (11.97 feet)
Height
3.42 m (11.22 feet)
Loading Platform Height (Laden)
1.30 m (4.26 feet)
Length of Platform (including slope)
8.70 m (28.54 feet)
Loading Area Length
7.60 m (24.93 feet)
Ground Clearance
0.35 m (1.15 feet)
Tyres and Wheels
Size of Tyres
12.00 X 20 (Ply rating : 18)
Number of Tyres
17 (8 tyres / axle plus 1 spare tyre)
12.00 X 20 (Ply rating : 18)
Number of Tyres
17 (8 tyres / axle plus 1 spare tyre)
Service Brake
Brake System
Two line air brake system
Parking Brakes
Spring loaded hand operated
Two line air brake system
Parking Brakes
Spring loaded hand operated
Landing Ramps
Type
Spring aided
Angle of Ramps
20 degrees
Spring aided
Angle of Ramps
20 degrees
Electric System
Voltage
24 V
24 V
التعديل الأخير:
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
ARMOURED VEHICLE LAUNCHED BRIDGE
Description
Quick launching of bridge
Bridge can sustain all military vehicles up to 60 - ton weight
Entire bridging operation controlled by a two - man crew
Crew / operator enjoys armour protection
It a 13.5 meter (44.3 feet) span class - 60 scissor type foldable steel and aluminum alloy which can be launched by a standard AVLB launcher installed on turret less tank M47M. The bridge can be launched into position in approximately three minutes. The entire operation i.e. launching and retrieving is controlled from within the tank and the crew has therefore complete armour protection throughout the operation. This bridge (in its existing configuration) can be tandem launched with another medium or short span AVLB thus extending bridging span to 29 meter (95.15 feet) and 23.5 meter (77.1) feet respectively.
Specification
ARMOURED VEHICLE LAUNCHED BRIDGE
SPECIAL FEATURES
Rapid bridging operation across wet and dry gaps Quick launching of bridge
Bridge can sustain all military vehicles up to 60 - ton weight
Entire bridging operation controlled by a two - man crew
Crew / operator enjoys armour protection
It a 13.5 meter (44.3 feet) span class - 60 scissor type foldable steel and aluminum alloy which can be launched by a standard AVLB launcher installed on turret less tank M47M. The bridge can be launched into position in approximately three minutes. The entire operation i.e. launching and retrieving is controlled from within the tank and the crew has therefore complete armour protection throughout the operation. This bridge (in its existing configuration) can be tandem launched with another medium or short span AVLB thus extending bridging span to 29 meter (95.15 feet) and 23.5 meter (77.1) feet respectively.
Specification
TECHNICAL SPECIFICATIONS
Dimensions of Folded AVLB (Installed on Turretless Tank M47M)
Length
10.8 m (35.43 feet)
Height
3.61 m (11.84 feet)
Width
4.0 m (13.12 feet)
10.8 m (35.43 feet)
Height
3.61 m (11.84 feet)
Width
4.0 m (13.12 feet)
Dimensions of Launched AVLB
Length
13.5 m (44.29 feet)
Height
0.914 m (2.99 feet)
Width
4.0 m (13.12 feet)
Distance between two Treadways
0.96 m (3.15 feet)
13.5 m (44.29 feet)
Height
0.914 m (2.99 feet)
Width
4.0 m (13.12 feet)
Distance between two Treadways
0.96 m (3.15 feet)
Other Specifications
Maximum Clear Span
12.5 m (41.0 feet)
Control Equipment
Electro - Hydraulic
Classification
Class - 60
Total weight of bridge layer with M47M Chassis
51 Ton
Bridge weight
7.0 Ton (approx.)
Time for Launching or Retrieving
3 min
Crew
2 men (Commander and driver / bridge operator
12.5 m (41.0 feet)
Control Equipment
Electro - Hydraulic
Classification
Class - 60
Total weight of bridge layer with M47M Chassis
51 Ton
Bridge weight
7.0 Ton (approx.)
Time for Launching or Retrieving
3 min
Crew
2 men (Commander and driver / bridge operator
التعديل الأخير:
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
صناعة الغواصات طراز اجوستا90B في الباكستان
http://www.youtube.com/watch?v=PtRTnq-gF10
صناعة الغواصات طراز اجوستا90B في الباكستان
http://www.youtube.com/watch?v=PtRTnq-gF10
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
http://www.youtube.com/watch?v=KwU2K9OIHnE
http://www.youtube.com/watch?v=Bu_finsiinc
http://www.youtube.com/watch?v=KwU2K9OIHnE
http://www.youtube.com/watch?v=Bu_finsiinc
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
نعم الباكستان صناعة القصير مدى الصواريخ عنزة عنزةMK و عنزةMK2.عنزه هو لدمر ٢ طائرات ميغ21 و ميغ27 هيليكوبتر MI-17
هنديه في الحرب كارغل 1998
طائرة هنديه ميغ21 بعد ضرب عنزة :a020[2]:
وهذة الطيار ميغ ٢١ FL.nachi keta في الحراسة باكستانية عندما نزل في اراضي الباكستاني.بعد ما اطلق سراح من الباكستان هو اليوم بطل الهندي ولكن في الحقيقة بطل هو عسكري الباكستاني التي ضرب على ميغ٢١
نعم الباكستان صناعة القصير مدى الصواريخ عنزة عنزةMK و عنزةMK2.عنزه هو لدمر ٢ طائرات ميغ21 و ميغ27 هيليكوبتر MI-17
هنديه في الحرب كارغل 1998
طائرة هنديه ميغ21 بعد ضرب عنزة :a020[2]:
وهذة الطيار ميغ ٢١ FL.nachi keta في الحراسة باكستانية عندما نزل في اراضي الباكستاني.بعد ما اطلق سراح من الباكستان هو اليوم بطل الهندي ولكن في الحقيقة بطل هو عسكري الباكستاني التي ضرب على ميغ٢١
التعديل الأخير:
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
الطائرة بدون طيار الباكستانى هما-١ huma-1
الطائرة بدون طيار الباكستانى هما-١ huma-1
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
الطائرة بدون طيار الباكستانى نسر حارس الحدود border eagle
الطائرة بدون طيار الباكستانى نسر حارس الحدود border eagle
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
غرفة تحكم الطائرات بدون طيار الباكستانى
غرفة تحكم الطائرات بدون طيار الباكستانى
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
جهاز تحكم الطائرات بدون طيار الباكستانى لعساكر التي في المواقع حدوديه بعيدة او في الوقت الحرب متنقله
جهاز تحكم الطائرات بدون طيار الباكستانى لعساكر التي في المواقع حدوديه بعيدة او في الوقت الحرب متنقله
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
جهاز تحكم الطائرات بدون طيار الباكستانى لعساكر التي في المواقع حدوديه بعيدة او في الوقت الحرب متنقله
http://www.satuma.com.pk/Multimedia.aspx
جهاز تحكم الطائرات بدون طيار الباكستانى لعساكر التي في المواقع حدوديه بعيدة او في الوقت الحرب متنقله
http://www.satuma.com.pk/Multimedia.aspx
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
غرفة تحكم الطائرات بدون طيار الباكستانى صناعة شركة ستوما struma الباكستانى
http://www.satuma.com.pk/Multimedia.aspx
غرفة تحكم الطائرات بدون طيار الباكستانى صناعة شركة ستوما struma الباكستانى
http://www.satuma.com.pk/Multimedia.aspx
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
الطائرة فليمغوFlamingo بدون طيار الباكستانى صناعة شركة ستوما struma الباكستانى لمدة الطيران هو ٨ ساعات
الطائرة فليمغوFlamingo بدون طيار الباكستانى صناعة شركة ستوما struma الباكستانى لمدة الطيران هو ٨ ساعات
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
الطائرة رعد thunder بدون طيار الباكستانى صناعة شركة ستوما struma الباكستانى محمول الصاروخ
الطائرة رعد thunder بدون طيار الباكستانى صناعة شركة ستوما struma الباكستانى محمول الصاروخ
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
غرفة تحكم الطائرات بدون طيار الباكستانى من الخارج صناعة شركة ستوما struma الباكستانى
غرفة تحكم الطائرات بدون طيار الباكستانى من الخارج صناعة شركة ستوما struma الباكستانى
- إنضم
- 2 ديسمبر 2009
- المشاركات
- 4,249
- التفاعل
رد: الصناعة العسكرية الباكستانية
مصانع صناع المدرعات HIT الباكستانى
مصانع صناع المدرعات HIT الباكستانى
المواضيع المشابهة
