الكلام على ان ت-90 غير دقيقة كلام غير صحيح ...................... اذا الابرامز نجت من قذيفة موجهه للدبابات فالت-90 نجحت بالنجاة من التاو في سوريا ونجت من 7 قذائف ر ب ج في الشيشان ......................
الت-90 تستطيع ضرب الابرامز من مسافة 5 كم بدقة كبيرة The T-90MS is equipped with a guided missile system designed to defeat armored targets, including those equipped with explosive reactive armor (ERA), at ranges up to 5 km.
انظمة التصويب الروسية لم تعد تقل عن الغربية بشيء ..ت-90 تساطيع ضرب الاهداف اثناء التوقف والحركة بدقة كبيرة
Fire-control system of the T-90 showed the following features of combat shooting during state testing. Heavily armoured targets at ranges of up to 5 km were hit by tank T-90 on the move (up to 30 km/h) with a high probability of hit with the first shot. During state testing made 24 launches of missiles at ranges of 4–5 km and they all hit the target (all missile launches were made by inexperienced professionals). An experienced gunner at speeds of 25 km/h hit 7 real armoured targets located at ranges of 1,500–2,500 m and 54sec.[55][56]
Fire-control system on the T-90 includes the PNK-4S/SR AGAT day and night sighting system mounted at the commanders station which allows for night time detection of a tank sized target at ranges between 700 and 1100 metres depending on the version of the sight. Early models of the T-90 were equipped with the TO1-KO1 BURAN sight but later models (T-90S) were upgraded to use the ESSA thermal imaging sight, which allows for accurate firing to a range of 5,000–8,000m using the CATHERINE-FC thermal camera produced by Thales Optronique. The gunner is also provided with the 1G46 day sighting system which includes a laser range finder, missile guidance channel and allows tank-sized targets to be detected and engaged at 5 to 8 kilometres (3.1 to 5.0 mi). The driver uses a TVN-5 day and night sight.[52] In 2010, Russia started licensed production of Thales-developed Catherine FC thermal imaging cameras for T-90M tanks, a Russian daily said.[57] These thermal imagers are also present on T-90M "Bhishma" built in India under licence.[29]
In 2012, the Russian-made combined sample of commander supervisory-sighting system T01-K04DT/Agat-MDT was presented to the public. According to Krasnogorsky Zavod plant, Agat-MDT has the ability to be installed (for further modernization) in the sight of the newly developed domestic UPF format 640×512 by 15 microns, which is possible in the future to extend the range of target identification at night to 3.5 — 4.0 km without sight modifications.[14] In 2016, the Krasnogorsk plant finished testing the Irbis-K night-vision gunner's sighting system for the T-80U and T-90, with first deliveries in 2018.[58] Completion of the Irbis-K, the first Russian-produced mercury-cadmium-telluride (MCT) matrix thermal sight, will bridge a gap with the leading NATO countries in this area. The Irbis-K is capable of identifying targets at ranges up to 3,240 meters during both day and night.[15]
The Russian-made thermal imaging device not only meant that Russian tanks would no longer need to be equipped with foreign parts, but it also meant that complete tank modernization was cheaper. Furthermore, there will be no decrease in demand for the T-72 and the T-90 in the next few years. The new tank gunner’s heat-vision sight Irbis-K and the commander’s combined sighting and observation system Agat-MDT can be supplied to T-72, T-80 and T-90 upgraded versions (T-72B3M, T-80BVM, T-90M...), replacing Catherine-FC thermal camera from Thales.
