ماذا عن الكورفيت بينونة بتسليح مكثف كالتالي
General characteristics
Type:
Displacement: 915 tons
Length: 71.3 m (234 ft)
Beam: 11 m (36 ft)
Draft: 2.8 m (9 ft 2 in)
Propulsion: 4 ×
12V595 TE90
3 ×
models 112S11 and 125B11
Speed: 30+ knots
Range: 2,400 nmi (4,400 km; 2,800 mi) at 15 knots (28 km/h; 17 mph)
Endurance: 14 days
Complement: 37 officers and crew
Sensors and
processing systems:
Sea Giraffe AMB surveillance radar
Terma I-band navigation radar
Selex Orion RTN 25 Fire Control X-band radar
NDS 3070 Vanguard hull-mounted mine and obstacle avoidance sonar
Armament: 1 ×
2 ×
27 mm guns
8 × MBDA MM40 block 3
missiles
1 × mk49 mod3 21-cell RAM launcher for
missile system
Aviation facilities: Aft helicopter deck and hangar
وماذا عن مواصفات ابوظبي كلاس ( متخصص في صيد الغواصات المعادية + دفاع جوي )
Specifications
Type
Anti-Submarine Warfare Corvette
Crew
70
Operators
UAE Navy
Performance
Speeds: 25+ kts (max)
Range: 3,000+ nm @ 14 kts
Endurance: 20 days at sea
Designer / Builder
Fincantieri
Displacement
1,650 tons (full load)
Aviation
Spot and Hangar for 1x 10 tons class helicopter
Dimensions
Length: 88.40 m
Beam: 12.20 m
Maximum Draft: 8.20 m
Missions
» Patrol in the EEZ
» Surveillance
» ASW, AAW, ASUW
Deck Equipment
» Helicopter deck: for 10 tons helicopter
» Helicopter hangar: for 10 tons helicopter
» Boats: 2 x RHIB
Weapons
Guns:
» 1x Oto Melara 76/62 mm Super Rapid main gun
» 2x Oto Melara Marlin 30 mm remote controlled naval turret
» 2x 12.7 mm machine guns
Missiles:
» 4x MBDA MM40 Blk III Exocet Anti-ship missiles (2 launchers with 2 missiles each)
Torpedoes:
» 2x Torpedo launchers
Sensors, Electronics, Decoys
- Combat Management and Information Systems:
SELEX Sistemi Integrati Athena (IPN-S System) Combat Management System
- Optronics:
1x Optronic Fire Control System
- Radars, Sonars and ESM:
1x Air & Surface Surveillance Radar System
1x IFF Interrogator
1x Radar ESM
1x X-band Navigation Radar with frequency diversity
1x X-band Navigation Radar with LPI component
1x Thales KINGKLIP UMS 4132 HMS (Hull Mounted Sonar)
1x Thales CAPTAS 2 / UMS 4229 VDS (Variable Depth Sonar)
Expendable Bathythermograph Ssytem
- Decoys/Counter measures/Jammers:
2x Anti-torpedoes decoy launching system
2x AAW decoy launching system
- Communications:External Communication System with Data Link
Internal Communication System
Satcom Communication System
Detailed View
Pictures - Video
اليسوا جديرين بمرافقة الجميلة ميسترال !!
