تركتوا المهم ورحتوا تردون على الي يخربون المواضيع،
معلومات عن الرادار:
مدى ٤٠ كم
تغطية ٣٦٠
مصمم خصيصا لصواريخ الكروز والطائرات بدون طيار ومقاوم بدرجة كبيرة على الهجمات الإلكترونية والتشويش
The
AN/MPQ-64 Sentinel is a
3D radar used to alert and queue
Short Range Air Defense(SHORAD)
weapons to the locations of hostile targets approaching their front line forces.
The Sentinel radar is deployed with forward area
air defense units of the
U.S. Army. It is an
X-band range-gated,
pulse-Doppler radarsystem. The
antenna uses
phase-frequency electronic scanning technology, forming sharp 3D pencil beams covering large surveillance and track volume. The radar automatically acquires, tracks,
classifies, identifies and reports targets, including
cruise missiles,
unmanned aerial vehicles, and both rotary- and fixed-wing
aircraft. It uses a high scan rate (30 RPM) and operates at a range of 40 km (25 mi).
The radar is designed with high resistance to
electronic countermeasures (ECM). Mounted on a towed platform, it can be positioned remotely from the rest of the unit, operated
autonomouslyand communicate with the
Fire Distribution Center (FDC) via
wideband fiber-optic link. It can also distribute its data over a
SINCGARSradio network.
