يا مسلم افهم فيه فرق بين اتفاقيات بين شركات سعوديه والشركات المصنعه وببن واحد يشتري جوال ايفون ويقولك انا اصنع جوال ايفون
مستوعب انت تتكلم في ايش ولا تبي تخلط كل شي ببعضه لمجرد الخلط ؟
- إنضم
- 25 نوفمبر 2009
- المشاركات
- 8,199
- التفاعل
- الدولة
الشرح بيطول وندخل في جدال لا فائده منه
عشان اوصل الفكرة لازم اوضح في الاتفاقيات وفكر التجميع عند الطرفين وطرق الحصول على المنتج النهائي
وفي الاخير ما اعتقد راح تصل الفكرة لاننا بندخل في جدال اكثر منه رغبه في ايضاح وتوصيل معلومه
عملية الشراء بحد ذاتها هي اتفاق بين طرفين لكن بعضهم يصور ويحتفل ليري العالم وبعضهم يراها وسيله للوصول بغايه .
عشان اوضح الفكره لازم افصل في الاتفاقيات التي تكون غالبيتها مذكرات تفاهم ولا ترقى لعملية شراء
وافصل في نوع المنتجات للشركات والزهراني مركبات غير مأهوله و دورنات
وبعدها افصل في الاسلوب المتبع من الطرفين للوصول للمنتج النهائي
واعتقد بعدها ماراح تصل الصوره بشكل واضح للكثير
لان الانتقاد غالبيته يكون شخصي وليس على فكره او طريقه وهذا مابي ادخل فيه نهائيا
- إنضم
- 30 نوفمبر 2013
- المشاركات
- 2,426
- التفاعل
انا معطيني بلوك مع اني ما اذكر اني منشنته بشيء
تستهبل يا رسلان
تراه مسجل بالمنتدى خصيصا علشان يرد عليك
حرام عليك حتى هو حرقت دمه
- إنضم
- 8 مارس 2009
- المشاركات
- 31,910
- التفاعل
- إنضم
- 5 أكتوبر 2011
- المشاركات
- 5,072
- التفاعل
Ground Control Station
The GCS has a portable form, contained in a ruggedized case for rapid and easy transport. However,
the GCS also has a configuration that is a permanent or semi-permanent installation in a building.
The datalink consists of a ground radio unit and its antennas. For extended range, the antennas are
mounted on a pan-tilt tracker unit that points the antennas at the aircraft to take advantage of high
gain directional antennas.
GSS is based on Human Machine Interface (HMI), which is the mission management system
developed by Intra Defense Technologies for unmanned aircraft. This interface provides
infrastructure and common functions that are required within tactical mission management systems
With adaptation and customizations depending on the project specific requirements.
Capabilities
The following tasks are possible using the GCS
• Authentication and authorization
• Flight planning on map and loading onto the UAV’s mission computer
• Tracking UAV on moving map
• Visualization of flight and mission data
• Monitoring subsystems’ status
• Displaying and listing alerts, warnings, and information conditions
• Generation of mission commands
• Mission checklist management
• Data link control
• Mission data recording
• Payload control and management
the GCS also has a configuration that is a permanent or semi-permanent installation in a building.
The datalink consists of a ground radio unit and its antennas. For extended range, the antennas are
mounted on a pan-tilt tracker unit that points the antennas at the aircraft to take advantage of high
gain directional antennas.
GSS is based on Human Machine Interface (HMI), which is the mission management system
developed by Intra Defense Technologies for unmanned aircraft. This interface provides
infrastructure and common functions that are required within tactical mission management systems
With adaptation and customizations depending on the project specific requirements.
Capabilities
The following tasks are possible using the GCS
• Authentication and authorization
• Flight planning on map and loading onto the UAV’s mission computer
• Tracking UAV on moving map
• Visualization of flight and mission data
• Monitoring subsystems’ status
• Displaying and listing alerts, warnings, and information conditions
• Generation of mission commands
• Mission checklist management
• Data link control
• Mission data recording
• Payload control and management
Mobile Ground Control Station (MGCS)
Ground Control Station (portable version)
GCS Case
• Size: 560 mm x 450 mm x 265 mm (closed)
• Housing Material: PP
• IP Rating: IP67 (closed)
• Working Environment: -20°C to 60°C
• Color: Matt Black
• Portable Features: Open and play, three proof delivery, With handle.
• battery & Working Time: Smart battery management system, 9 hrs enduranc•
Transmitter Solution with Tracking Antenna
• Ground terminal
• Air terminal.
• Battery charges for 5 hours (could be operated while charging)
• Tracking gimbal
• Gimbal tripod
• Panel antenna
• Size: 560 mm x 450 mm x 265 mm (closed)
• Housing Material: PP
• IP Rating: IP67 (closed)
• Working Environment: -20°C to 60°C
• Color: Matt Black
• Portable Features: Open and play, three proof delivery, With handle.
• battery & Working Time: Smart battery management system, 9 hrs enduranc•
Transmitter Solution with Tracking Antenna
• Ground terminal
• Air terminal.
• Battery charges for 5 hours (could be operated while charging)
• Tracking gimbal
• Gimbal tripod
• Panel antenna
- إنضم
- 5 أكتوبر 2011
- المشاركات
- 5,072
- التفاعل
- إنضم
- 5 أكتوبر 2011
- المشاركات
- 5,072
- التفاعل
sim A.Qureshi, Executive Director of Technology and Engineering Solutions at Intra, said
The aircraft will carry the company’s new AETOS 20-inch IR/EO turret, and Intra hope to provide a completely ITAR-free and indigeno
solution, having already demonstrated indig
The aircraft will carry the company’s new AETOS 20-inch IR/EO turret, and Intra hope to provide a completely ITAR-free and indigeno
solution, having already demonstrated indig
