السعودية والامارات تشتريان مدافع من نوع نيمو120 مم للقوات البحرية والبرية

ARABIC

صقور الدفاع
إنضم
2 ديسمبر 2013
المشاركات
3,182
التفاعل
13,380 0 0
Two customers have ordered the NEMO turret-mounted mortar system, with deliveries already under way. GDLS Canada has signed a contract for 36, for installation on Light Armoured Vehicles (LAVs) being supplied to the Saudi Arabian National Guard (SANG).
السعودية اقتنته لتضعه على 36 عربة من العربات التي اقتنتها من كندا
The United Arab Emirates have ordered eight naval versions for installation on their new coastal craft and these have a stabilised fire-on-the-move capability and are optimised for use in the harsh naval environment.
والامارات طلبت 8 منه للبحرية لديها
النسخه البحريه


النسخة البرية

بالنسبة للسعودية ........ هذه المدافع مخصصة للحرس الوطني السعودي

شكرا على الخبر اخوي @ ARABIC ARABIC
وتقييم

كم يبلغ مداه ؟؟


  • Barrel:
    • Calibre: 120 mm
    • Length: 3 m
  • Angles: -3° to +85°
  • Side angles: n × 360°
  • Lock: half-automatic wedge
  • Lifting device: hydro-pneumatic
  • Fire preparation time: < 30 seconds
  • Leave preparation time: < 10 seconds
  • Rate of fire: 10 shots/minute (max); 7 shots/minute (continuous)
  • Complement: 3 men
  • Weight: ca. 1,500 kg
http://en.wikipedia.org/wiki/Patria_NEMO

http://www.patria.fi/en/news+and+ev...avy+mortar+system+for+naval+applications.html


هذا ماوجدته .. اما المدفع المركب على العربة فيبلغ مداه الاقصى 10 كم بحسب موقع Military Today

http://www.military-today.com/artillery/nemo_mortar_system.htm


النسخه البحريه



في الدقيقه 1.22 ارى زورق غرناطه من جهة اليمين وهو محمل بهذا البرج .. ممتاز والى الامام

في الدقيقه 1.22 ارى زورق غرناطه من جهة اليمين وهو محمل بهذا البرج .. ممتاز والى الامام


هناك عدد 12 من زوارق فئة ( غناضة كلاس ) تصنعها شركة ابوظبي لبناء السفن .. عدد 6 تم تزويدها بصواريخ مارتي ER وعدد 6 سيتم تزويدها بمدافع نيمو البحرية ( آخر جزئية في الخبر )

DpnXYxmY7C4dveW2LFIvuTl72eJkfbmt4t8yenImKBVvK0kTmF0xjctABnaLJIm9


هذه غناضة - مارتي ER ( عدد 4 صواريخ مارتي - القاتل البحري )


فئة غناضة كلاس


شرح حولها

Naval Ship Building – Ghannatha Class 27m Fast Missile Boat



The Ghannatha Class Fast Missile Boats are high speed multi-role Combat Vessels and can be utilized as a unit of a task force, as a single unit or in non-combat operations.

Operational requirements.

The operational capability of this vessel within a task force context can provide a missile attack mission coordinated role and provide interoperability with other ships and shore centers. As a single unit as well as missile attack missions maybe utilized for enforcement of sanctions, trade embargo or blockades or shadowing hostile vessels. This vessel may also be used for search and rescue surveillance and control of sea lanes and pollution control.

Construction:

Hull and deck as well as wheelhouse / bilge arrangement constructed in aluminum.

General description of Combat System:

The Combat System suite is designed to accommodate the vessel with the best conditions to be prepared to exploit the Marte Missile System capabilities in both the task force mission or stand alone operations. The GEM Radar provides accurate target indications and track data with good discrimination. The vessel is also fitted with Medusa E/O System to preform day and night optical surveillance and a 27mm and 12.7nn gun, all integrated to a Combat Management System which manages the self-defense system. The communications system consists of V-UHF and HF for tactical and data communications and is interfaced to CMS.

Propulsion System

The propulsion system consists of 2 MTU main engines to drive 2 Rolls-Royce FF 600 water jets giving speed of 45 knots.


ملف PDF لبقية المنتجات
file:///C:/Documents%20and%20Settings/Administrator/My%20Documents/Downloads/ADSBBrochure.pdf

مناسب لتقديم الدعم الناري للقوات على الارض عن طريق البحر

رمي من وضع الحركة .. ميزة مهمة

Patria Nemo - a compact and modern, turreted mortar system. Patria Nemo is a turreted, remote-controlled 120 mm mortar system. It is an indirect-fire support system, but due to its direct fire capability, it can also be used for self-defence. The turret and the armoured chassis protect the crew against battlefield contaminants, shrapnel, and bullets from light infantry weapons, while the highly mobile chassis provides the vehicle with manoeuvrability that enables it to survive in the modern battlefield. The light and compact turret is easily installable on light, tracked chassis, boats or wheeled armoured vehicles in the 6x6/8x8 class. A complement to Patria's range of mortar systems, the Nemo offers the best price/quality ratio on the market, providing a lightweight, flexible fire-support system that can be adapted to a wide range of uses in response to needs arising in new market areas and customers.

http://www.military.com/video/guns/naval-guns/120mm-mortar-system-on-landing-craft/3547046540001/

المثير في الموضوع انه يمكن دمجه ( بسبب وزنه الخفيف وبرجه المدمج ) على المجنزرات والسفن والعربات المدرعة المدولبة من فئتي 6x6/8x8
